Some News Pertaining to the Physics-Specific Modules… We are using selections to quickly specify a plot for the electric field norm on this component. In this example, radiation emitted from an antenna induces an electric current on the outer surface of the cable harness in a car. We’re also happy to introduce dual y-axes in 1D plots to enable you to plot different quantities of different scales in two y-axes in one graph. In other general news, viewing results with multiple parameters is now simpler with quick filters built on sections. In this example, pyramid elements (cyan) are automatically generated around a swept mesh’s hexahedrons (green) the rest of the space is filled with tetrahedrons (gray). It’s also possible to automatically combine swept and tetrahedral meshes via a transition layer of pyramid elements in COMSOL Multiphysics version 5.3. Administrators of the COMSOL Server™ product, the app deployment and management platform, can take advantage of user log files and centralized cluster settings.Īnother exciting improvement involves building geometries and defining physics operations more easily by specifying local coordinates. When building apps, you now have the ability to create more interactive simulation tools with data picking support in the improved Graphics form object of the Application Builder. For example, you can build a method to use data from a text file to set up a geometry. This method functionality is now also available in the Model Builder, so you can perform complex modeling tasks with ease. If you already use the Application Builder, you’re familiar with functionality that allows you to record methods, edit, and then run them. It is especially noticeable in the case of larger models, which are now much faster to work with and load - speedups reach up to a factor of ten.
#COMPONENT COMSOL 5.3 SOFTWARE#
Performance improvements are the name of the game with COMSOL® software version 5.3 - and they are significant. It’s Here: Introducing COMSOL Multiphysics® and COMSOL Server™ Version 5.3 The Ray Optics Module and Wave Optics Module will also benefit from the addition of a new Optical Materials Database.Ready to speed up your modeling? Today, we released a new version of the COMSOL Multiphysics® software and COMSOL Server™, version 5.3, and we think you’ll love the performance improvements.
Ready-to-use parametric geometry components are now available to use with any module, and a library of dedicated parts has been created for the Microfluidics Module, Mixer Module, Ray Optics Module, and Structural Mechanics Module. Version 5.1 also introduces enhancements to the existing functionalities of COMSOL Multiphysics and its add-on products. The updated Application Library in COMSOL Server features new grid, detail, and list views with information on which add-on products are needed to create a particular application.
Designers will also be able to run applications on multiple computers with COMSOL Server.ĬOMSOL Server can now be run on multiple computers, allowing computations to be run on a separate machine from where the app is being launched.
#COMPONENT COMSOL 5.3 FULL#
Upgrades to the Application Builder are said to include full integration between the Model Builder and Application Builder, improved layout tools for app design, and LiveLink for Excel capabilities in applications.
